PU Braid Air Hose Reel
PU Braid Air Hose Reel
● Open type.
● Handy crank hose reel.
● Heavy duty reinforced steel construction with power paint coating.
● Supplied with foldable handle to rewind the hose after use.
● 4 PC rubber stoppers to hold the reel in place when in use.
● Includes mounting bracket and hardware for wall mounting.
● Easy to mount and dismount from the wall for outdoor use.
● Easily stored away.
● Can be fixed on the wall and stored indoors. Also portable for outdoor use.
● Small in size.
● Reasonable price.
PU Braid Air Hose Reel
● Frame standard color: Black
● Case standard color: Black
● Hose standard color: Red
|
Model No. |
Hose I.D |
Max.Working |
Bursting |
Inlet |
Outlet |
Hose |
Thread |
Weight |
|||
|
mm |
inch |
psi |
bar |
psi |
bar |
cm |
m |
in + outlet |
kg |
||
|
HR07DX6520 |
6.5 |
1/4 |
200 |
15 |
800 |
60 |
110 |
20 |
PU Braid |
1/4 + 1/4 |
6.0 |
|
HR07DX6525 |
6.5 |
1/4 |
200 |
15 |
800 |
60 |
110 |
25 |
PU Braid |
1/4 + 1/4 |
6.0 |
|
HR07DX6530 |
6.5 |
1/4 |
200 |
15 |
800 |
60 |
110 |
30 |
PU Braid |
1/4 + 1/4 |
6.0 |
|
HR07DX8010 |
8.0 |
5/16 |
200 |
15 |
800 |
60 |
110 |
10 |
PU Braid |
1/4 + 1/4 |
6.3 |
|
HR07DX8015 |
8.0 |
5/16 |
200 |
15 |
800 |
60 |
110 |
15 |
PU Braid |
1/4 + 1/4 |
6.3 |
|
HR07DX8020 |
8.0 |
5/16 |
200 |
15 |
800 |
60 |
110 |
20 |
PU Braid |
1/4 + 1/4 |
6.3 |
|
HR07DX9510 |
9.5 |
3/8 |
200 |
15 |
800 |
60 |
110 |
10 |
PU Braid |
3/8 + 3/8 |
6.5 |
|
HR07DX9515 |
9.5 |
3/8 |
200 |
15 |
800 |
60 |
110 |
15 |
PU Braid |
3/8 + 3/8 |
6.5 |
|
HR07DX9520 |
9.5 |
3/8 |
200 |
15 |
800 |
60 |
110 |
20 |
PU Braid |
3/8 + 3/8 |
6.5 |
PU Braid Air Hose Reel
● Works with suitable pneumatic tools
● Used for construction work areas, automatic maintenance and manufacturing facilities.
● U.S-Patent No.: D586202S
● E.U.-Patent No.: 000826144-0001
● CANADA-Patent No.: 123379
● TAIWAN-Patent No.: D127728
