Model No.

DTDP2-006CN-OR
DTDP2-006CU-OR

DTDP2-012CN-OR
DTDP2-012CU-OR

DTDP2-020CN-OR
DTDP2-020CU-OR

DTDP2-030CN-OR
DTDP2-030CU-OR

DTDP3-060CN-OR
DTDP3-060CU-OR

DTDP3-085CN-OR
DTDP3-085CU-OR

CN

CU

CN

CU

CN

CU

CN

CU

CN

CU

CN

CU

Torque Accuracy

CW:+-3%
CCW:+-4%

Max Operation
Range

6 N-m
4.424 ft-lb
53.09 in-lb
61.22 kg-cm

12 N-m
8.85 ft-lb
106.2 in-lb
122.4 kg-cm

20 N-m
14.75 ft-lb
177 in-lb
204.1 kg-cm

30 N-m
22.12 ft-lb
265.5 in-lb
306.1 kg-cm

60 N-m
44.24 ft-lb
530.9 in-lb
612.2 kg-cm

85 N-m
62.7ft-lb
752 in-lb
867 kg-cm

Measured Torque
Range

0.3~6 N-m

0.6~12 N-m

1~20 N-m

1.5~30 N-m

3~60 N-m

4.25~85 N-m

Resolution

0.001 N-m

0.01 N-m

0.01 N-m

0.01 N-m

0.01 N-m

0.1 N-m

Bright LED

2 LED ( 1 Red + 1 Green)

Operation Mode

Peak hold / Track

Unit Selection

N-m;in-lb;ft-lb;kg-cm

Length (mm)

216

216

216

216

239

239

Square Drive

1/4"

1/4"

1/4"

1/4"

3/8"

3/8"

 Gear Teeth

60

60

60

60

48

48

Data Memory Size

50

250

50

250

50

250

50

250

50

250

50

250

Communication

No

Yes

No

Yes

No

Yes

No

Yes

No

Yes

No

Yes

Button

5

Battery

AAA X 1

Battery Life
(Continuous operation)

12 hrs.

Battery Life  (Standby)

1 year

Operating
 Temperature

 -10~60

Storage
Temperature

 -20~70

 Humidity

Up to 90% non-condensing

Drop Test

1m

Vibration Test

10G

Life Time

10000 cycle

Enviromental Test

Pass

Electromagnetic
Compatibility Test

Pass
