Model No.

DTAF2-030AN-OR
DTAF2-030BN-OR

DTAF3-135AN-OR
DTAF3-135BN-OR

DTAF4-135AN-OR
DTAF4-135BN-OR

DTAF4-200AN-OR
DTAF4-200BN-OR

DTAF4-340AN-OR
DTAF4-340BN-OR

AN

BN

AN

BN

AN

BN

AN

BN

AN

BN

Accuracy

CW:+-1%
CCW:+-2%

CW:+-2%
CCW:+-3%

CW:+-1%
CCW:+-2%

CW:+-2%
CCW:+-3%

CW:+-1%
CCW:+-2%

CW:+-2%
CCW:+-3%

CW:+-1%
CCW:+-2%

CW:+-2%
CCW:+-3%

CW:+-1%
CCW:+-2%

CW:+-2%
CCW:+-3%

Angle

+/-2 degree  (rotating 90 degree at speed of 30 degree /sec)

Max Operation
Range

30 N-m
22.12 ft-lb
265.5 in-lb
306.1 kg-cm

135 N-m
99.5 ft-lb
1195 in-lb
1378 kg-cm

135 N-m
99.5 ft-lb
1195 in-lb
1378 kg-cm

200 N-m
147.5 ft-lb
1770 in-lb
2041 kg-cm

340 N-m
250.7 ft-lb
3009 in-lb
3469 kg-cm

Torque & Angle
Measured Range

1.5~30 N-m
1.11~22.12 in-lb
13.3~265.5 in-lb
15.3~306.1 kg-cm

6.8-135 N-m
5~99.5 ft-lb
60~1195 in-lb
69~1378 kg-cm

6.8-135 N-m
5~99.5 ft-lb
60~1195 in-lb
69~1378 kg-cm

10~200 N-m
7.4~147.5 ft-lb
88~1770 in-lb
102~2041 kg-cm

17~340 N-m
12.5~250.5 ft-lb
150~3009 in-lb
173~3469 kg-cm

Resolution

0.01 N-m
0.01 ft-lb
0.1 in-lb
0.1 kg-cm

0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm

0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm

0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm

0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm

Bright LED

12 LED ( 4 Reds + 8 Greens)

Operation Mode

Peak hold / Track

Unit Selection

N-m;in-lb;ft-lb;kg-cm; Angle

Length (mm)

390

415

415

530

650

Square Drive

1/4"

3/8"

1/2"

1/2"

1/2"

Gear Teeth

36

Communication

No

Button

4

Battery

AA X 2

Battery Life
(Continuous operation)

60 hrs.

Battery Life (Standby)

1 year

Operating Temperature

-10~60

Storage Temperature

-20~70

Humidity

Up to 90% non-condensing

Drop Test

1m

Vibration Test

10G

Life Time

10000 cycle

Enviromental Test

Pass

Electromagnetic
Compatibility Test

Pass
